Review of Filters for Air Sampling and Chemical Analysis in Mining Workplaces

Details

• Alternative Title:
  Minerals (Basel)
• Personal Author:
  Chow, Judith C. ; Watson, John G. ; Wang, Xiaoliang ; Abbasi, Behrooz ; Reed, Wm. Randolph ; Parks, David
• Description:
  This review considers the use of filters to sample air in mining workplace environments for dust concentration measurement and subsequent analysis of hazardous contaminants, especially respirable crystalline silica (RCS) on filters compatible with wearable personal dust monitors (PDM). The review summarizes filter vendors, sizes, costs, chemical and physical properties, and information available on filter modeling, laboratory testing, and field performance. Filter media testing and selection should consider the characteristics required for mass by gravimetry in addition to RCS quantification by Fourier-transform infrared (FTIR) or Raman spectroscopic analysis. For mass determination, the filters need to have high filtration efficiency (≥99% for the most penetrable particle sizes) and a reasonable pressure drop (up to 16.7 kPa) to accommodate high dust loading. Additional requirements include: negligible uptake of water vapor and gaseous volatile compounds; adequate particle adhesion as a function of particle loading; sufficient particle loading capacity to form a stable particle deposit layer during sampling in wet and dusty environments; mechanical strength to withstand vibrations and pressure drops across the filter; and appropriate filter mass compatible with the tapered element oscillating microbalance. FTIR and Raman measurements require filters to be free of spectral interference. Furthermore, because the irradiated area does not completely cover the sample deposit, particles should be uniformly deposited on the filter.
• Subjects:
  Article Chemical Speciation Filter FTIR Personal Dust Monitor Raman Respirable Coal Mine Dust Respirable Crystalline Silica
• Source:
  Minerals (Basel). 12(10)
• Pubmed ID:
  37180428
• Pubmed Central ID:
  PMC10174218
• Document Type:
  Journal Article
• Funding:
  CC999999/ImCDC/Intramural CDC HHSUnited States/
• Volume:
  12
• Issue:
  10
• Collection(s):
  CDC Public Access
• Main Document Checksum:
  urn:sha256:3ff905c25c665a3dae0926150f4e80c407d84ceb8c34a0dbcb6dc26ef6fcb1bc
• Download URL:
  https://stacks.cdc.gov/view/cdc/128464/cdc_128464_DS1.pdf
• File Type:
  [PDF - 1.45 MB ]
